A two-gang weatherproof outlet box with threaded 1/2 in. conduit hubs, intended for surface mounting where devices are exposed to weather, washdown or damp conditions. The hubs thread directly onto rigid or IMC conduit and fittings, so the raceway itself forms part of the seal instead of relying on a knockout and connector.

The box holds two devices side by side - duplex receptacles, switches, or a combination - and is finished with a gasketed weatherproof cover chosen to suit the devices inside. Hubs that are not used for conduit entry are closed with threaded plugs to keep the enclosure sealed. Mounting lugs on the back allow the box to be fastened flat to a wall, post or structural member with the conduit run exposed.

Key Features

• Two-gang configuration accepts a pair of wiring devices side by side
• Threaded conduit hubs for direct connection to rigid or IMC conduit and threaded fittings
• Machined, gasketed cover seating surface for use with weatherproof covers and device gaskets
• Unused hubs can be closed with threaded plugs to maintain the seal of the enclosure
• Surface-mount design with integral mounting lugs for fastening to walls, posts or framing
• Suited to exposed conduit systems where flush boxes are not practical
• Sold individually as a box; covers, gaskets and plugs are separate items

Applications

• Exterior wall receptacles and switch locations on houses and light commercial buildings
• Surface-mounted device boxes on exposed rigid or IMC conduit runs
• Garages, workshops, barns and other damp or unfinished interiors
• Decks, patios, porches and yard equipment outlets
• Mechanical rooms, loading docks and service areas subject to moisture or washdown
• Two-device stations combining a receptacle and a switch in one outdoor enclosure

Product Details

• Product Type: Weatherproof outlet box
• Configuration: 2-gang
• Hub Size: 1/2 in.
• Size: 4 in.
• Mounting: Surface mount
• Hub Type: Threaded
• Use Location: Outdoor, damp and wet locations when fitted with a weatherproof cover and gasket
• Unit of Measure: Each
